| Tên thương hiệu: | Sinuo |
| Số mẫu: | SN553-EV22HG120VT120.GP.VCSUSB-2 |
| MOQ: | 1 |
| Điều khoản thanh toán: | T/T |
| Khả năng cung cấp: | 10 bộ mỗi tháng |
| Parameter | Specification |
|---|---|
| Maximum sinusoidal excitation force | 2200Kg.f peak |
| Maximum Random Exciting Force | 2200Kg.f rms |
| Maximum impact excitation force | 4400Kg.f |
| Frequency Range | 1～3000 Hz |
| Maximum displacement | 51 mm p-p |
| Maximum speed | 2.0m/s |
| Maximum acceleration | 100G (980 m/s²) |
| First-order resonant frequency | 2600 Hz±5% |
| Payload | 300 kg |
| Vibration isolation frequency | 2.5 Hz |
| Moving coil diameter | Ф340 mm |
| Moving coil weight | 22kg |
| Screw on the table | 17×M10 |
| Flux leakage | ＜10gauss |
| Equipment size | L 1080mm×W 920mm×H 950mm (vertical table) |
| Equipment weight | 1920Kg (Excluding horizontal slide table) |
| Parameter | Specification |
|---|---|
| Output power | 20KVA |
| Output voltage | 120V |
| Output current | 200A |
| Amplifier efficiency | ≥90% |
| Switching frequency | 116KHz |
| SNR | ≥65dB |
| Noise | ≤70dB |
| Amplifier weight | 500KG |
| Amplifier size | W600mm×D 900mm×H 1280mm |
