| Tên thương hiệu: | Sinuo |
| Số mẫu: | SN4411 |
| MOQ: | 1 |
| Điều khoản thanh toán: | T/T |
| Khả năng cung cấp: | 10 bộ mỗi tháng |
| Inner Tank Diameter | 350mm |
| Internal Tank Height | 590mm |
| External Dimensions | Approximately 360mm outer diameter * 900mm height |
| Stainless Steel Thickness | 5mm |
| Time Control | 1～99999 seconds |
| Pressure Management | Manual adjustment |
| Pressure Display | Touchscreen display for pressure setting and monitoring |
| Pressure Adjustment Range | Atmospheric pressure to 500 kPa (1-50m water depth) |
| Maximum Limit Pressure | Factory configurable with pressure switch protection (typically 550 kPa auto-vent) |
| Pressure Protection | Spring-loaded safety relief valve; Program control with automatic shutdown and pressure release |
| Pressure Release Method | Automatic pressure release after test completion |
| Lid Operation | Manual opening and closing |
| Pressurization System | External air supply (user provided, ≥ 5 kg) |
| Control System | Touch screen control |
| Container Material | 304 stainless steel |
| Drain Pipe Diameter | 1/2 inch pipe |
| Power Requirements | AC 220-240V, 50Hz±10%; Power: 1KW; Separate 16A circuit breaker required |
| Environmental Conditions | Temperature: 15℃ to 35℃; Relative humidity: 25% RH to 75% RH; Atmospheric pressure: 86 kPa to 106 kPa |
| 0.1 MPa | = 1 Kg/cm² = 10M water depth |
| 0.2 MPa | = 2 Kg/cm² = 20M water depth |
| 0.3 MPa | = 3 Kg/cm² = 30M water depth |
| 0.4 MPa | = 4 Kg/cm² = 40M water depth |
